Basic Info
| Model No. | BC-A350C-EC-07 | Fan Type | EC Axial Fan |
| Nominal Voltage | 230 VAC | Frequency | 50/60 Hz |
| Nominal Speed | 1550 RPM | Operating Mode | S1 |
| Max. Input Power | 170 W | Max. Input Current | 2.5 A |
| Sound Level | 65 dBA | Certification | CCC, RoHS |
Technical Description
| Dimensions | 350 × 350 × 109 mm | Motor Type | External Rotor EC Motor |
| Impeller Material | Plastic | Bearing Type | Ball Bearing |
| Direction of Rotation | Counterclockwise, seen on rotor | Rotor Surface | Plastic spraying |
| Type of Protection | IP55 | Insulation Class | B |
| Ambient Temperature | -25 °C to 60 °C | Humidity | 5%-90% RH |
| Motor Protection | Locked rotor, thermal, low-voltage and excessive-voltage protection | ||
| Cable Length | 500 ± 20 mm | RoHS | All parts meet RoHS requirements |
Product Application
| 1 | Ventilation equipment | 9 | Equipment cooling projects |
| 2 | Air handling units | 10 | Cabinet ventilation |
| 3 | Industrial cooling | 11 | Control cabinets |
| 4 | HVAC systems | 12 | Heat exchanger equipment |
Air Performance
Air performance data are shown in the product specification. The measured curve range is 0-3200 m³/h and 0-220 Pa.
Overal Dimmensions
Outline dimensions: 350 × 350 × 109 mm. Cable length: 500 ± 20 mm.
Electrical Connection
| PE | Green/Yellow | Protective Earth |
| U1 / L | Brown | Live wire |
| U2 / N | Blue | Neutral wire |
| U4 | Red | +10 VDC output |
| U5 | Yellow | 0-10 V / PWM speed control |
| U6 | White | FG signal feedback |
| U7 | Blue | Control-line ground |
Download
BC-A350C-EC-07 Technical Specification.pdf0C-EC-0
